北京市行政副中心機關辦公區工程地質剖面圖------下載
擬建場地位于北京市通州區潞城鎮，運河?xùn)|大街南北兩側。
土層編號
巖性
壓縮模量
標準貫入
Es (MPa)
N
P0+100
P0+200
P0+300
kPa
kPa
kPa
①
粉質粘土-粘質粉土填土
3.90
3.90
7
①1
房渣土
②
粉質粘土-重粉質粘土
4.16
4.98
7.15
7
②1
粘質粉土-砂質粉土
6.22
7.47
13.27
9
②2
(有機質)重粉質粘土-粘土
3.20
4.00
②3
粉砂--細砂
8.00
11
③
細砂
20.00
19
③1
粉砂
5.00
15
③2
粉質粘土
5.76
6.48
7.83
9
③3
粘質粉土-砂質粉土
7.47
8.58
11.60
10
④
細砂-中砂
25.00
33
④1
粉質粘土-重粉質粘土
6.09
7.40
7.53
16
④2
粘質粉土-砂質粉土
11.70
13.70
14.90
20
④3
(有機質)重粉質粘土-粘土
4.80
5.30
5.80
⑤
細砂-中砂
43
⑤1
粉質粘土-重粉質粘土
8.78
9.60
9.48
47
⑤2
粘質粉土-砂質粉土
9.60
10.20
10.90
⑤3
（有機質)重粉質粘土-粘土
⑥
細砂-中砂
32.00
49
⑥1
粉質粘土-重粉質粘土
9.86
10.77
11.44
23
⑥2
粘質粉土-砂質粉土
16.29
18.88
31
⑥3
有機質-重粉質粘土-粘土
9.05
9.50
21
⑦
粉質粘土-重粉質粘土
12.79
14.14
⑦1
粘質粉土-砂質粉土
19.08
21.74
26
⑦2
粘土
12.22
12.86
27
⑦3
（有機質）重粉質粘土-粘土
15.50
15.50
⑦4
細砂-中砂
35.00
55
⑧
粉質粘土-重粉質粘土
⑧1
細砂
35.00
78
⑨
粉質粘土-重粉質粘土
⑨1
細砂
40.00
⑩
細砂-中砂
40.00
93
土層編號
巖性
分層承載力標準值
樁的極限側阻力標準值
樁的極限端阻力標準值
fka
qsik
qpk
kPa
kPa
kPa
①
粉質粘土-粘質粉土填土
①1
房渣土
②
粉質粘土-重粉質粘土
80
30
②1
粘質粉土-砂質粉土
110
35
②2
(有機質)重粉質粘土-粘土
80
25
②3
粉砂--細砂
120
30
③
細砂
150
45
③1
粉砂
130
35
③2
粉質粘土
100
35
③3
粘質粉土-砂質粉土
120
45
④
細砂-中砂
240
65
④1
粉質粘土-重粉質粘土
160
55
④2
粘質粉土-砂質粉土
180
55
④3
(有機質)重粉質粘土-粘土
160
40
⑤
細砂-中砂
260
80
1300
⑤1
粉質粘土-重粉質粘土
180
60
⑤2
粘質粉土-砂質粉土
240
65
⑤3
（有機質)重粉質粘土-粘土
160
40
⑥
細砂-中砂
300
85
1600
⑥1
粉質粘土-重粉質粘土
200
⑥2
粘質粉土-砂質粉土
240
⑥3
有機質-重粉質粘土-粘土
180
⑦
粉質粘土-重粉質粘土
240
⑦1
粘質粉土-砂質粉土
280
⑦2
粘土
220
⑦3
（有機質）重粉質粘土-粘土
200
⑦4
細砂-中砂
320
⑧
粉質粘土-重粉質粘土
260
⑧1
細砂
350
⑨
粉質粘土-重粉質粘土
280
⑨1
細砂
350
⑩
細砂-中砂
400
